Precision Design. Perfect Capture.
With meticulous design and innovative structure, it effectively captures and locks in grease and smoke.
The wide air inlet combined with smooth exhaust ensures a complete grease control system, keeping your kitchen air clean and fresh.
Touch and Wave Gesture Control
Touch controls combined with wave sensor allow convenient, hygienic operation.
Efficient Quiet BLDC Motor
Uses BLDC inverter motor with 1290 Pa static pressure and 2100 m³/h airflow. Triple-layer centrifugal filtration filters grease efficiently. Silence+ tech keeps noise down to 48 dB.
Optimal Grease and Smoke Control Zone
Optimal smoke capture zone is set at 580mm above the hob to quickly trap grease and smoke, preventing spread.
Wider Chamber Entrance
Wider air inlet (~20mm) captures smoke from multiple burners, enhancing smoke extraction efficiency.
110-Degree Buffer Plate Design
Blunt smoke compression technology with 160mm ultra-wide buffer plate improves grease compression and smoke prevention.
Airborne Grease Highway
Airborne grease passes through a 4-pointed straight line leading grease and smoke from the chamber entrances to the exhaust in one straight line with zero to minimal obstruction.
Intelligent Suction and Extraction System
Auto Turbo System – Automatically boosts extraction power when resistance is detected.
Memory Function – Stores user preferences for an enhanced experience.
Easy To Clean
Dual removable grille filters – Easy to detach and wash directly in the sink, making maintenance simple and convenient.
Large-capacity oil cup – Reduces cleaning frequency and keeps the unit cleaner.
Specifications
 |
|
| Model | JQG9009X |
| Product Type | Inclined Range Hood |
| Power Supply | 220-240V/50Hz |
| Motor Type | Brushless DC Inverter Motor (BLDC) |
| Lighting | 1.5W*2 |
| No. of Speeds Fan Control | 3 Level |
| Max IEC Airflow | 1440 m³/hr |
| Noise Level | Auto : 58 dB / High : 52 dB / Low : 48 dB |
| Max Static Pressure | 1290 Pa |
| Odor Reduction Rate | 99% |
| Grease Separation Rate | 92% |
| Delayed Shut-Off Function | Yes |
| Control | Touch + Hand-Wave |
| Filter Type | Dual Removable Grille Filters |
| Key Features | Wide-Angle Open Design, Automatic Cruise Boost, Intelligent Suction and Extraction System, Memory Function |
| Dimension (WxDxH) | 895 x 437 x (629-1293) mm |
| Origin | China |
| Maintenance Period | 2 Years |
